BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.

Read more
THE 5BMW 5 SERIES SEDAN: ENGINES & TECHNICAL DATA

BMW 5 SERIES SEDAN: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,685
Max. permissible weight in kg 2,285
Permitted load in kg 675
Permitted axle load front/rear in kg 1,080/1,280
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 120-135 (163-184)/5,000-6,500
Engine torque (Nm) at 1/min 290/1,350-4,250 - 1,350-3,800
Compression ratio : 1 11.0

Performance

Top speed in km/h 226-235
Acceleration 0–100 km/h in s 8.6-7.8
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 8.5
Extra-urban in l/100 km 5.8
Combined in l/100 km 6.8
CO2 combined emissions in g/km 156
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,700
Max. permissible weight in kg 2,305
Permitted load in kg 680
Permitted axle load front/rear in kg 1,090/1,300
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 185 (252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.4-6.1
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 8.1
Extra-urban in l/100 km 5.9
Combined in l/100 km 6.7
CO2 combined emissions in g/km 154
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,755
Max. permissible weight in kg 2,360
Permitted load in kg 680
Permitted axle load front/rear in kg 1,140/1,310
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 183-185 (249-252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.3-6.0
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 8.9
Extra-urban in l/100 km 6.3
Combined in l/100 km 7.3
CO2 combined emissions in g/km 166
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,760
Max. permissible weight in kg 2,395
Permitted load in kg 710
Permitted axle load front/rear in kg 1,155/1,320
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 2245-50 (333-340)/5,500-6,250 - 5,500-6,500
Engine torque (Nm) at 1/min 450/1,600-4,800 - 1,500-5,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.2-5.1
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 10.1
Extra-urban in l/100 km 6.3
Combined in l/100 km 7.7
CO2 combined emissions in g/km 176
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,820
Max. permissible weight in kg 2,455
Permitted load in kg 710
Permitted axle load front/rear in kg 1,200-1,330
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 245-250 (333-340)/5,500-6,250 - 5,500-6,500
Engine torque (Nm) at 1/min 450/1,600-4,800 - 1,500-5,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.9-4.7
Electrical engine top speed in km/h -

Fuel consumption

Urban in l/100 km 10.2
Extra-urban in l/100 km 6.6
Combined in l/100 km 7.9
CO2 combined emissions in g/km 182
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 225/55 R17 97 Y
Tyre dimensions rear 225/55 R17 97 Y
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp



** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.

Read more

Fuel consumption and CO2 emissions.

  • BMW 540i Sedan:
    Fuel consumption in l/100 km (combined): 7.7
    CO2 emissions in g/km (combined): 176

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
