BMW 2 SERIES GRAN COUPÉ: TECHNICAL DATA.

Discover the powerful petrol engines as well as the dimensions and other technical data of the BMW 2 Series Gran Coupé.

Read more
THE 2BMW 2 SERIES GRAN COUPÉ: TECHNICAL DATA.
BMW 2 Series Gran Coupé

BMW 2 SERIES GRAN COUPÉ: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,425 [1,450]
Max. permissible weight in kg 1,885 [1,905]
Permitted load in kg 535 [530]
Permitted axle load front/rear in kg 1,000/970 [1,025/970]
Luggage capacity min. (seats up) in l 430
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 710 [725]
Trailer load 8% (braked) in kg N/A [N/A]
Trailer load 12% (braked) in kg 1,300 [1,300]

Engine

Cylinders/valves 3/4
Capacity in ccm 1.499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 100-103 (136-140)/4,500-6,500
Engine torque (Nm) at 1/min 220/1,480-4,200
Compression ratio : 1 11

Performance

Top speed in km/h 213 [213]

Fuel consumption

Urban in l/100 km 8.0 [7.2]
Extra–urban in l/100 km 5.3 [5.2]
Combined in l/100 km 6.3 [5.9]
CO2 combined emissions in g/km 144 [135]
Tank capacity, approx. in l 42

Wheels

Tyre dimensions front 205/55 R16 91 W
Tyre dimensions rear 205/55 R16 91 W
Wheel dimensions and material front 7 J x 16 inches, light-alloy
Wheel dimensions and material rear 7 J x 16 inches, light-alloy

Weight

Unladen weight EU in kg 1,505
Max. permissible weight in kg 1,965
Permitted load in kg 535
Permitted axle load front/rear in kg 1,060/980
Luggage capacity min. (seats up) in l 430
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg N/A
Trailer load 12% (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131-141 (178-192)/4,750-6,000
Engine torque (Nm) at 1/min 280/1,350-4,600
Compression ratio : 1 11.0

Performance

Top speed in km/h 238

Fuel consumption

Urban in l/100 km 7.9-7.8
Extra–urban in l/100 km 5.5-5.4
Combined in l/100 km 6.3
CO2 combined emissions in g/km 145-144
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/45 R17 94 Y XL
Tyre dimensions rear 225/45 R17 94 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,595
Max. permissible weight in kg 2,060
Permitted load in kg 540
Permitted axle load front/rear in kg 1,100/1,040
Luggage capacity min. (seats up) in l 430
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg N/A
Trailer load 12% (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131 (178)/4,750-5,500
Engine torque (Nm) at 1/min 280/1,350-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 234

Fuel consumption

Urban in l/100 km N/A
Extra–urban in l/100 km N/A
Combined in l/100 km N/A
CO2 combined emissions in g/km N/A
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/45 R17 94 Y XL
Tyre dimensions rear 225/45 R17 94 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Weight

Unladen weight EU in kg 1,645
Max. permissible weight in kg 2,105
Permitted load in kg 535
Permitted axle load front/rear in kg 1,140/1,040
Luggage capacity min. (seats up) in l 430
Luggage capacity max. (seats down) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 225 (306)/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250

Fuel consumption

Urban in l/100 km 9.3
Extra–urban in l/100 km 6.6-6.3
Combined in l/100 km 7.6-7.4
CO2 combined emissions in g/km 173-169
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 225/40 R18 92 Y XL
Tyre dimensions rear 225/40 R18 92 Y XL
Wheel dimensions and material front 8 J x 18 inches, light-alloy
Wheel dimensions and material rear 8 J x 18 inches, light-alloy
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
​

Fuel consumption and CO2 emissions.

  • BMW M235i xDrive Gran Coupé:
    Fuel consumption in l/100 km (combined): 7.8–7.2
    CO2 emissions in g/km (combined): 175–162

    BMW 220i xDrive:
    Fuel consumption in l/100 km (combined): 7.4–6.5
    CO2 emissions in g/km (combined): 166–149

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.
